| Type |
LOVSON Diesel Engine is SINGLE CYLINDER, vertical, totally enclosed
compression ignition, four stroke cycle, cold starting diesel
engine tested as per IS 11170-1985. |
 |
| Cumbustion |
DIRECT INJECTION : cumbustion takes places in a cavity on the
top of the Aluminum Alloy Piston in order to minimise power
loss usually occuring because of gas leakage & heat loss,
resulting in powerful performance, low fuel consumption &
easy start. |
|
| Rotation |
Standard
Rotation is clockwise when viewed from flywheel end. Engine
with Reverse Rotation (Anti clockwise/Counter clockwise) can
be built against specific requirement. |
|
| Lubrication |
INTERNAL
MOVING PARTS ARE PARTLY LUBRICATED BY FORCE FEED LUBRICATION
through a lubricating pump and partly by SPLASH LUBRICATING
SYSTEM. |
|
| Cooling |
Forced
air cooling of cylinder head/s & cylinder block/s by fan
/ rotor fitted on flywheel. |
|
| Balancing |
Engine is balanced with two balance weights bolted on crank shaft. Flywheel is balanced for longer life of moving parts. |
|
| Drive |
STANDARD
power take off is from flywheel side at full speed. Power take-off
from gear end at half / full engine speed can be provided against
specific requirement. |
|
| Fuel System |
Fuel is supplied to the fuel pump by gravity feed through wire mesh filter in fuel tank & efficient paper element filter in fuel filter. |
